CNC Lathe Chuck Jaws
Use the series index to identify the relevant jaw family, then open the series page for drawings, dimensions and parameter notes. Final compatibility is confirmed against the exact chuck model and interface before quotation.
Find a jaw family by chuck type or model series
Search examples: SC08, 1.5 à 60°, scroll chuck, DIN, JIS, POM or T-Nut.
01 / HYDRAULICStandard Hydraulic Soft Jaws
SC-04 through SC-79; common 1.5 × 60° and 3.0 × 60° serrations.
Shown: CS-05 standard soft jaws
02 / SPECIAL FORMExtra-Height Soft Jaws
Catalog height ranges from 50 mm to 200 mm depending on series.
Shown: 6-inch custom 150 mm-height soft jaws
03 / SPECIAL FORMPointed Soft Jaws
60°, 90° and 120° point forms for supported SC interfaces.
Shown: 8-inch top-pointed soft jaws
04 / SPECIAL FORMExtra-Width Soft Jaws
Catalog width and height combinations for SC06, SC08 and SC10.
Shown: 6-inch widened hydraulic-chuck jaws
05 / MATERIALPOM Soft Jaws
Standard and pointed engineering-plastic jaw forms.
Shown: POM soft jaws for hydraulic chucks
06 / HARD JAWSHydraulic Chuck Hard Jaws
HJ series hard jaws for supported hydraulic chuck interfaces.
Shown: HJ-15 steel standard hard jaws
07 / SCROLL CHUCKScroll Chuck Soft Jaws
CP series from CP-04 through CP-20 plus HE-2486.
Shown: 6-inch manual scroll-chuck soft jaws08 / POWER & SCROLLWedge and Scroll Chuck Jaws
K51/K51T/K51F, K52/K54/K55 and RZ families.
Shown: 6-inch scroll-chuck soft jaws09 / DINDIN-Series Top Jaws
Inch and metric serrated jaws plus tongue-and-groove soft blanks.
Shown: Standard soft blank jaw10 / JISJIS-Series Jaws
Serrated, tongue-and-groove, S1 and hard-jaw types.
Shown: 6-inch soft top jaws11 / PRECISION CHUCKSuper-Precision Chuck Jaws
J-04, J-06 and J-08 jaw drawings are included in the catalog.
Shown: 10-inch high-precision lathe hard jaws
12 / ACCESSORIEST-Nuts & Boring Rings
DIN, JIS and power-chuck T-Nuts grouped as supporting accessories.
Shown: lathe chuck soft-jaw boring ringNo matching series. Send the chuck model or jaw drawing for identification.
Send these details for a compatibility review
- Chuck brand, exact model and nominal size
- Through-hole or non-through configuration
- Serration pitch and angle or tongue-and-groove dimensions
- Jaw drawing or clear photos with measured dimensions
- Required form, material, quantity and delivery date
- Workpiece profile and inspection requirement for custom jaws
